Model NO.:
Product Specifications
| Part No. | Torque Comparison | |||||||||
| 36T | 48T | 72T | Size | L(mm) | Width | Chief | Ansi | Din | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 20636 | 20648 | 20672 | 1/4"Dr. | 159mm | 25mm | 27mm | 150g | 82N.M | 51N.M | 62N.M |
| 30636 | 30648 | 30672 | 3/8"Dr. | 242mm | 33mm | 32mm | 374g | 275N.M | 204N.M | 202N.M |
| 40636 | 40648 | 40672 | 1/2"Dr. | 290mm | 42mm | 42mm | 662g | 714N.M | 509N.M | 512N.M |
| Packing(T3) | |||||
| Size | Inner box | CTN | NW | GW | CUFT |
|---|---|---|---|---|---|
| 1/4"Dr. | 25 | 100 | 16.5kg | 17.5kg | 1' |
| 3/8"Dr. | 12 | 48 | 19.0kg | 20.0kg | 0.8' |
| 1/2"Dr. | 6 | 24 | 16.5kg | 17.5kg | 0.7' |
